FEATURES
- Comfort tuned MC9 carbon frame, featuring Masi's proven endurance geometry, fully convertible internal cable routing, 1.5" tapered headtube, BB86 press-fit BB, flat mount disc, 12mm thru axle & removable fender mounts
- Comfort tuned MC9 tapered full carbon fork with 12mm thru axle, flat mount disc and removable fender mounts
- Shimano Ultegra R8020 shifters & R8000 derailleurs
- Shimano Ultegra R8070 hydraulic disc brakes for all-condition stopping power
- Brev.M Elite 3D forged stem & SL bar
- Praxis Works Zayante M30 cranks with new 48/32t right-size gearing featuring a 1:1 low gear
- Brev.M Elite AR thru-axle tubeless compatible wheelset featuring custom Brev.M CNC machined hubs and AR21 endurance rims with 21mm internal width
- Kenda Valkyrie 30mm 120tpi tires
- Clearance for up to a 35mm tire
| Frame Components | |
|---|---|
| Frame | "Masi Comfort Tuned-Carbon MC9 Carbon frame, fully convertible internal cable routing, BB86 press-fit BB, tapered headtube, flat mount disc, 12mm thru-axle & removeable fender mounts, Di2 Compatible " |
| Fork | Masi Comfort Tuned MC9 Carbon Tapered 1.5" Steerer, 12mm Thru-Axle, Flat Mount Disc Brake, w/ Removable Fender Mounts |
| Headset | Masi by Token 1.5" Tapered |
| Drivetrain | |
| Cranks | Praxis Works Zayante M30 48/32t |
| Bottom Bracket | Praxis Works M30 by Enduro |
| Chain | KMC X11 |
| Front Derailleur | Shimano Ultegra R8000 |
| Rear Deralleur | Shimano Ultegra R8000 |
| Derailleur Shifter | Shimano Ultegra R8020 |
| Pedals | N/A |
| Wheels | |
| Tires | Kenda Valkyrie 30mm |
| Wheels/Rims | Brev M. AR21 Tubeless Compatible, 21mm Int. |
| Hubs | Brev M. Elite Alloy Disc Sealed Bearing Center Lock, Thru-Axle, 24h |
| Freewheel/Cassette | New Shimano 105 R7000 11-32t 11-spd |
| Braking System | |
| Brakes | Shimano Ultegra R8070 Hydraulic Disc |
| Brake Levers | Shimano Ultegra R8020 |
| Other Components | |
| Grips | Masi Gripper Silicon Gel |
| Handle Bar | Brev. M Elite Compact Bend Alloy |
| Stem | Brev. M Elite 3D Forged Alloy |
| Seat | Masi Corsa Comp |
| Seat Post | Brev. M Carbon, 27.2mm |
| Seat Clamp | Alloy 31.8mm |
| Extras | Removeable Fender Mounts |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 71° | 74° | 515mm (20.3") | 43mm (1.7") | 425mm (16.7") | 73mm (2.9") | 992mm (39.1") | 729mm (28.7") | 530mm (20.9") | 363mm (14.3") | 50mm (2") | 90mm | 400mm | 165mm | |
| S | 72° | 74° | 530mm (20.9") | 46.5mm (1.8") | 425mm (16.7") | 73mm (2.9") | 993mm (39.1") | 758mm (29.8") | 554mm (21.8") | 371mm (14.6") | 45mm (1.8") | 90mm | 400mm | 170mm | |
| M | 72.5° | 73° | 545mm (21.5") | 50mm (2") | 425mm (16.7") | 70mm (2.8") | 995mm (39.2") | 788mm (31") | 572mm (22.5") | 370mm (14.6") | 45mm (1.8") | 100mm | 420mm | 170mm | |
| M/L | 72.5° | 73° | 560mm (22") | 53.5mm (2.1") | 425mm (16.7") | 68mm (2.7") | 1006mm (39.6") | 815mm (32.1") | 591mm (23.3") | 379mm (14.9") | 40mm (1.6") | 100mm | 420mm | 172.5mm | |
| L | 72.5° | 72° | 580mm (22.8") | 55.5mm (2.2") | 425mm (16.7") | 68mm (2.7") | 1014mm (39.9") | 830mm (32.7") | 610mm (24") | 382mm (15") | 40mm (1.6") | 110mm | 440mm | 172.5mm | |
| XL | 72.5° | 72° | 600mm (23.6") | 58.5mm (2.3") | 425mm (16.7") | 65mm (2.6") | 1035mm (40.7") | 853mm (33.6") | 626mm (24.6") | 397mm (15.6") | 40mm (1.6") | 110mm | 440mm | 175mm |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
