FEATURES
- Masi MC7 carbon frame, Di2 compatible, PF30, internal routing, tapered headtube
- Masi FC/Pro Taper monocoque carbon fork
- Sram Red PF30 53/39 crankset
- Ritchey WCS carbon Evo bar / Ritchey WCS carbon C-260 stem
- Ritchey WCS Carbon Streem saddle
- Ritchey WCS 1 bolt carbon seatpost
- Mercury M3 front / Mercury M5 rear carbon clincher wheelset
- Kenda Kountach 25c folding bead, 120tpi tires
| Frame Components | |
|---|---|
| Frame | Masi MC7 carbon, Di2 compatible, PF30, internal routing, tapered headtube |
| Fork | Masi FC / Pro Taper monocoque carbon |
| Headset | Ritchey Pro Logic Taper headset |
| Drivetrain | |
| Cranks | Sram Red PF30, 53/39 |
| Bottom Bracket | Sram Red, Press Fit 30 |
| Chain | Sram PG-1190 |
| Front Derailleur | Sram Red |
| Rear Deralleur | Sram Red |
| Derailleur Shifter | Sram Red |
| Pedals | N/A |
| Wheels | |
| Tires | Kenda Kountach 25c folding bead, 120tpi |
| Wheels/Rims | Mercury S3 front / Mercury S5 rear carbon clincher |
| Freewheel/Cassette | Sram PG-1190, 11 speed, 11-26t |
| Braking System | |
| Brakes | Sram Red |
| Brake Levers | Sram Red |
| Other Components | |
| Grips | Masi cork tape |
| Handle Bar | Ritchey WCS Evo Curve, 31.8mm |
| Stem | Ritchey WCS 4-Axis |
| Seat | Ritchey WCS Carbon Streem |
| Seat Post | Ritchey WCS 1 bolt carbon, 31.6 x 350mm |
| Seat Clamp | Alloy SL |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 72° | 74° | 520mm (20.5") | 470mm (18.5") | 410mm (16.1") | 68mm (2.7") | 965mm (38") | 712mm (28") | 45mm (1.8") | ||||||
| 50 | 72.5° | 74° | 530mm (20.9") | 500mm (19.7") | 410mm (16.1") | 68mm (2.7") | 975mm (38.4") | 744mm (29.3") | 45mm (1.8") | ||||||
| 53 | 73° | 74° | 545mm (21.5") | 530mm (20.9") | 410mm (16.1") | 68mm (2.7") | 986mm (38.8") | 764mm (30.1") | 45mm (1.8") | ||||||
| 56 | 73.5° | 73.5° | 565mm (22.2") | 560mm (22") | 410mm (16.1") | 68mm (2.7") | 996mm (39.2") | 797mm (31.4") | 45mm (1.8") | ||||||
| 59 | 73° | 73.5° | 585mm (23") | 590mm (23.2") | 410mm (16.1") | 68mm (2.7") | 1021mm (40.2") | 817mm (32.2") | 45mm (1.8") | ||||||
| 62 | 73° | 73.5° | 595mm (23.4") | 620mm (24.4") | 410mm (16.1") | 68mm (2.7") | 1031mm (40.6") | 842mm (33.1") | 45mm (1.8") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
