FEATURES
- Masi MA4 double-butted alloy w/ integrated headtube
- Masi Elite/RS carbon integrated fork w/ 7075 alloy steerer
- FSA Tempo crankset; 50/34 w/ sealed cartridge BB
- Shimano Sora shifters, front and rear derailleur
- Sunrace CSM-90 cassette 11-32T 9-speed
- Brev. M 31.8 alloy bar / Brev. M 3-D forged flip/flop stem
- Masi SLS saddle
- Brev. M alloy seatpost
- Alloy 24/28h cassette hubs w/ alloy QR
- Brev. M 24/28 Race rims
- Kenda Kontender 26c tires
- Tektro R312 dual pivot brakeset
| Frame Components | |
|---|---|
| Frame | Masi MA4 double-butted alloy w/ internal rear brake routing and integrated headtube |
| Fork | Masi Elite / RS carbon integrated w/ 7075 alloy steerer |
| Headset | FSA 23/CC internal |
| Drivetrain | |
| Cranks | FSA Tempo, 50/34 |
| Bottom Bracket | FSA square taper |
| Chain | Taya TB-90 |
| Front Derailleur | Shimano Sora |
| Rear Deralleur | Shimano Sora |
| Derailleur Shifter | Shimano Sora |
| Pedals | Nylon body |
| Wheels | |
| Tires | Kenda Kontender 26c wire bead |
| Wheels/Rims | Brev. M 24/28h rims, alloy cassette hubs, stainless spokes |
| Freewheel/Cassette | Sunrace CSM-90, 9 speed, 11-32t |
| Braking System | |
| Brakes | Tektro R312 |
| Brake Levers | Shimano Sora |
| Other Components | |
| Grips | Masi cork tape |
| Handle Bar | Brev. M Bellissima alloy, 31.8mm |
| Stem | Brev. M 3-D forged alloy |
| Seat | Masi Bellissima |
| Seat Post | Brev. M Zero Offset alloy, 27.2 x 300mm |
| Seat Clamp | Alloy SL |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 71° | 75° | 505mm (19.9") | 470mm (18.5") | 408mm (16.1") | 70mm (2.8") | 965mm (38") | 722mm (28.4") | 50mm (2") | ||||||
| 49 | 72° | 74.5° | 520mm (20.5") | 490mm (19.3") | 408mm (16.1") | 70mm (2.8") | 973mm (38.3") | 722mm (28.4") | 50mm (2") | ||||||
| 51 | 72.5° | 74° | 530mm (20.9") | 510mm (20.1") | 408mm (16.1") | 70mm (2.8") | 972mm (38.3") | 743mm (29.3") | 45mm (1.8") | ||||||
| 53 | 73° | 73.5° | 540mm (21.3") | 530mm (20.9") | 412mm (16.2") | 70mm (2.8") | 976mm (38.4") | 760mm (29.9") | 45mm (1.8") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
