FEATURES
- Masi custom MA4 double-buttedalloy frame with integrated headtube
- Masi Elite/RS carbon fork with alloy steerer
- FSA Vero crankset 50/34 with sealed BB
- Shimano Tiagra 10 speed shifters, front and rear derailleurs
- Wide ratio 12-32T 10 speed cassette
- Brev. M oversize Bellissima alloy bar and forged flip/flop stem
- Masi Bellissima women's specific saddle
- Brev. M alloy zero offset seatpost
- Brev. M 30mm 20/24h Race rims
- Kenda Kriterium 25c tires
- Tektro R312 dual pivot brakeset with cartridge pads
| Frame Components | |
|---|---|
| Frame | Masi MA4 double-butted alloy w/ internal rear brake routing and integrated headtube |
| Fork | Masi Elite / RS carbon integrated w/ 7075 alloy steerer |
| Headset | FSA 23/CC internal |
| Drivetrain | |
| Cranks | FSA Vero, 50/34 |
| Bottom Bracket | FSA square taper |
| Chain | Shimano CN-4601 |
| Front Derailleur | Shimano Tiagra |
| Rear Deralleur | Shimano Tiagra |
| Derailleur Shifter | Shimano Tiagra |
| Pedals | N/A |
| Wheels | |
| Tires | Kenda Kriterium 25c wire bead |
| Wheels/Rims | Brev. M 20/24h rims, alloy cassette hubs, stainless spokes |
| Freewheel/Cassette | Sunrace CSRS, 10 speed, 12-32t |
| Braking System | |
| Brakes | Tektro R312 w/ cartridge pads |
| Brake Levers | Shimano Tiagra |
| Other Components | |
| Grips | Masi cork tape |
| Handle Bar | Brev. M Bellissima alloy, 31.8mm |
| Stem | Brev. M 3-D forged alloy |
| Seat | Masi Bellissima |
| Seat Post | Brev. M Zero Offset alloy, 27.2 x 300mm |
| Seat Clamp | Alloy SL |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 71° | 75° | 505mm (19.9") | 470mm (18.5") | 408mm (16.1") | 70mm (2.8") | 965mm (38") | 722mm (28.4") | 50mm (2") | ||||||
| 49 | 72° | 74.5° | 520mm (20.5") | 490mm (19.3") | 408mm (16.1") | 70mm (2.8") | 973mm (38.3") | 722mm (28.4") | 50mm (2") | ||||||
| 51 | 72.5° | 74° | 530mm (20.9") | 510mm (20.1") | 408mm (16.1") | 70mm (2.8") | 972mm (38.3") | 743mm (29.3") | 45mm (1.8") | ||||||
| 53 | 73° | 73.5° | 540mm (21.3") | 530mm (20.9") | 412mm (16.2") | 70mm (2.8") | 976mm (38.4") | 760mm (29.9") | 45mm (1.8") | ||||||
| 56 | 73.5° | 73° | 560mm (22") | 560mm (22") | 412mm (16.2") | 68mm (2.7") | 983mm (38.7") | 790mm (31.1") | 40mm (1.6") | ||||||
| 58 | 74° | 73° | 580mm (22.8") | 580mm (22.8") | 418mm (16.5") | 68mm (2.7") | 1004mm (39.5") | 812mm (32") | 40mm (1.6") | ||||||
| 60 | 74° | 72.5° | 595mm (23.4") | 600mm (23.6") | 418mm (16.5") | 68mm (2.7") | 1013mm (39.9") | 826mm (32.5") | 40mm (1.6") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
