FEATURES
- Masi double-butted alloy frame, PF30, w/ integrated headtube and disc mounts
- Masi Elite/RS carbon cross w/ 7075 alloy steerer w/ disc brake mounts
- Gossemer Cross crankset 46/36with PF30 BB
- New Shimano 105 11 speed shifters, front and rear derailleurs
- Shimano 5800 11-28t 11 speed cassette
- Deda RMH 01 alloy drop bar and Zero 1 stem
- ProLogo Kappa Evo saddle
- Deda RSX 01 alloy seatpost
- Weinmann XC180 28h rims
- Clement MXP 33c tires
- Tektro Lyra disc brakeset
| Frame Components | |
|---|---|
| Frame | Masi double-butted alloy, PF30, w/ integrated headtube |
| Fork | Masi Elite / RS Cross carbon integrated w/ 7075 alloy steerer & disc mount |
| Headset | FSA 23/CC internal |
| Drivetrain | |
| Cranks | FSA Gossamer Cross PF30, 46/36 |
| Bottom Bracket | FSA Press Fit 30 |
| Chain | Shimano HG-600 |
| Front Derailleur | Shimano 105 |
| Rear Deralleur | Shimano 105 |
| Derailleur Shifter | Shimano 105 |
| Pedals | N/A |
| Wheels | |
| Tires | Clement MXP 33c wire bead |
| Wheels/Rims | Weinmann XC-180 28h rims, alloy disc cassette hubs, stainless spokes |
| Freewheel/Cassette | Shimano CS-5800, 11 speed, 11-28t |
| Braking System | |
| Brakes | Tektro Lyra Disc |
| Brake Levers | Shimano 105 |
| Other Components | |
| Grips | Masi cork tape |
| Handle Bar | Deda RHM 01, 31.8mm |
| Stem | Deda Zero 01 84/6D |
| Seat | ProLogo Kappa Evo |
| Seat Post | Deda RXS 01, 27.2 x 350mm |
| Seat Clamp | Alloy SL |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 49 | 71° | 74° | 515mm (20.3") | 490mm (19.3") | 425mm (16.7") | 65mm (2.6") | 984mm (38.7") | 753mm (29.6") | 45mm (1.8") | ||||||
| 52 | 72° | 73.5° | 535mm (21.1") | 520mm (20.5") | 425mm (16.7") | 65mm (2.6") | 995mm (39.2") | 772mm (30.4") | 45mm (1.8") | ||||||
| 55 | 72° | 73° | 550mm (21.7") | 550mm (21.7") | 425mm (16.7") | 65mm (2.6") | 1006mm (39.6") | 800mm (31.5") | 45mm (1.8") | ||||||
| 57 | 72° | 73° | 570mm (22.4") | 570mm (22.4") | 425mm (16.7") | 65mm (2.6") | 1026mm (40.4") | 822mm (32.4") | 45mm (1.8") | ||||||
| 60 | 72° | 72.5° | 590mm (23.2") | 600mm (23.6") | 425mm (16.7") | 65mm (2.6") | 1041mm (41") | 847mm (33.3") | 45mm (1.8") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
