FEATURES
- All new Premiare frame featuring our MC3 carbon blend with internal cable routing
- Masi Elite/RS carbon integrated fork with carbon steerer
- FSA Omega; 50/34 crankset with 10 speed chainrings
- Shimano 105 front derailleur
- Shimano 105 rear derailleur
- Shimano 105 10-speed shifters
- Tektro R325 dual pivot brakeset with cartridge pads
- Ritchey Pro DS 20/24 rims
- Shimano 4600 cassette, 12-30t, 10-speed
- Alloy 20/24h cassette hubs with alloy QR
| Frame Components | |
|---|---|
| Frame | Masi T700 / MR60 / MR40 carbon w/ internal rear brake routing and integrated headtube |
| Fork | Masi Elite / RS carbon integrated w/ 7075 alloy steerer |
| Headset | FSA 23/CC internal |
| Drivetrain | |
| Cranks | FSA Omega, 50/34 |
| Bottom Bracket | FSA Mega EXO |
| Chain | Shimano CN-4601 |
| Front Derailleur | Shimano 105 |
| Rear Deralleur | Shimano 105 |
| Derailleur Shifter | Shimano 105 |
| Pedals | Nylon body |
| Wheels | |
| Tires | Kenda Kontender 26c wire bead |
| Wheels/Rims | Ritchey Pro DS 20/24h rims, alloy cassette hubs, stainless spokes |
| Freewheel/Cassette | Shimano CS-4600, 10 speed, 12-30t |
| Braking System | |
| Brakes | Tektro R325 w/ cartridge pads |
| Brake Levers | Shimano 105 |
| Other Components | |
| Grips | Masi cork tape |
| Handle Bar | Brev. M alloy, 31.8mm |
| Stem | Brev. M 3-D forged alloy |
| Seat | Masi SLS |
| Seat Post | Brev. M alloy, 31.6 x 300mm |
| Seat Clamp | Alloy SL |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XS | 71° | 74° | 515mm (20.3") | 43mm (1.7") | 420mm (16.5") | 73mm (2.9") | 986mm (38.8") | 714mm (28.1") | 50mm (2") | ||||||
| S | 72° | 74° | 530mm (20.9") | 46.5mm (1.8") | 420mm (16.5") | 73mm (2.9") | 988mm (38.9") | 751mm (29.6") | 45mm (1.8") | ||||||
| M | 72.5° | 73° | 545mm (21.5") | 50mm (2") | 420mm (16.5") | 70mm (2.8") | 990mm (39") | 776mm (30.6") | 45mm (1.8") | ||||||
| M/L | 72.5° | 73° | 560mm (22") | 53.5mm (2.1") | 420mm (16.5") | 68mm (2.7") | 1001mm (39.4") | 804mm (31.7") | 40mm (1.6") | ||||||
| L | 72.5° | 72° | 575mm (22.6") | 55.5mm (2.2") | 420mm (16.5") | 68mm (2.7") | 1004mm (39.5") | 823mm (32.4") | 40mm (1.6") | ||||||
| XL | 72.5° | 72° | 595mm (23.4") | 58.5mm (2.3") | 420mm (16.5") | 65mm (2.6") | 1025mm (40.4") | 849mm (33.4") | 40mm (1.6") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
