FEATURES
- Masi 6000 series double-butted alloy frame
- Masi Elite/RS fork carbon integrated with 7075 alloy steerer
- Shimano A070 7-speed shifters, front and rear deailleurs
- Forged alloy crankset 50/34 with sealed cartridge BB
- Sunrace CSR-63 cassette, 11-24t, 7-speed
- Brev. M 31.8 alloy bar / Brev. M forged flip/flop stem
- Tektro 510A dual pivot brakeset
| Frame Components | |
|---|---|
| Frame | Masi double-butted alloy w/ internal rear brake routing |
| Fork | Masi Elite / RS carbon integrated w/ 7075 alloy steerer |
| Headset | Ritchey Logic LB |
| Drivetrain | |
| Cranks | Forged alloy, 50/34 |
| Bottom Bracket | FSA square taper |
| Chain | Taya TB-50 |
| Front Derailleur | Shimano A070 |
| Rear Deralleur | Shimano A070 |
| Derailleur Shifter | Shimano A070 |
| Pedals | Nylon body |
| Wheels | |
| Tires | Kenda Kontender 26c wire bead |
| Wheels/Rims | Weinmann SEC 16 28h rims, alloy cassette hubs, stainless spokes |
| Freewheel/Cassette | Sunrace CSR-63, 7 speed, 11-24t |
| Braking System | |
| Brakes | Tektro 510A |
| Brake Levers | Shimano A070 |
| Other Components | |
| Grips | Masi cork tape |
| Handle Bar | Brev. M alloy, 31.8mm |
| Stem | Brev. M alloy |
| Seat | Masi SLS |
| Seat Post | Brev. M alloy, 27.2 x 300mm |
| Seat Clamp | Alloy SL |
| Size | Head Angle | Seat Angle | Top Tube (Effective) | Seat Tube (C-T) | Chainstay Length | BB Drop | Wheel Base | Stand Over | Stack Height | Reach | Fork Height | Fork Offset | Stem Length | Bar Width | Crank Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 47 | 71° | 75° | 502mm (19.8") | 470mm (18.5") | 408mm (16.1") | 73mm (2.9") | 966mm (38") | 728mm (28.7") | 50mm (2") | ||||||
| 49 | 72° | 74.5° | 520mm (20.5") | 490mm (19.3") | 408mm (16.1") | 70mm (2.8") | 973mm (38.3") | 739mm (29.1") | 50mm (2") | ||||||
| 51 | 72.5° | 74° | 530mm (20.9") | 510mm (20.1") | 408mm (16.1") | 70mm (2.8") | 972mm (38.3") | 759mm (29.9") | 45mm (1.8") | ||||||
| 53 | 73° | 73.5° | 540mm (21.3") | 530mm (20.9") | 412mm (16.2") | 70mm (2.8") | 981mm (38.6") | 765mm (30.1") | 45mm (1.8") | ||||||
| 56 | 73.5° | 73° | 560mm (22") | 560mm (22") | 412mm (16.2") | 68mm (2.7") | 983mm (38.7") | 795mm (31.3") | 40mm (1.6") | ||||||
| 58 | 74° | 73° | 580mm (22.8") | 580mm (22.8") | 418mm (16.5") | 68mm (2.7") | 1004mm (39.5") | 817mm (32.2") | 40mm (1.6") | ||||||
| 60 | 74° | 72.5° | 595mm (23.4") | 600mm (23.6") | 418mm (16.5") | 68mm (2.7") | 1013mm (39.9") | 830mm (32.7") | 40mm (1.6") |
RESOURCES
Owner's manual: Bike Manual PDF (Opens in a new window)
*Actual retail price may vary based on any added dealer freight, tax, and assembly fees
